Southern Pacific 6-Wheel Buckeye Tender Truck Drawings - Set #2 (used on GS 4-8-4's: GS-1,2,3,4,5,6)
$65.00
Skip to product information
Southern Pacific 6-Wheel Buckeye Tender Truck Drawings - Set #2 (used on GS 4-8-4's: GS-1,2,3,4,5,6)
Southern Pacific 6-Wheel Buckeye Tender Truck Drawings - Set #2 (used on GS 4-8-4's: GS-1,2,3,4,5,6)
$65.00
Drawing Set Includes:
| Drawing Number | Drawing Title | Drawing Size (in.) | Scale to 1 ft. |
| D-5172 | Equalizer | 36x20 | 3” |
| D-5173 | Journal Box | 34x20 | 6” |
| E-5191 | Side Frame | 34x42 | 3” |
| D-5202 | Journal Box Lid (Torsion Spring Type for 7” & 14” Journal Boxes) | 36x20 | Full |
| A-5401 | Locking Block | 12x8 | Full |
| B-5879 | Bill of Materials | 18x11 | None |
| E-5880 | Buckeye 6 Whl. Truck – Arrangement | 36x41 | 2” |
| E-5881 | Center Bolster | 34x42 | 3” |
| E-5883 | Side Frame | 34x41 | 3” |
| C-5884 | Air Cylinder Support Brackets | 24x16 | 4” |
| A-5885 | Locking Block Bolt | 12x8 | Full |
